DESCRIPTION

Overview

Basic Info.

Model NO.	CNC-BSM
Transport Package	Export Standard Free-Fumigation Wooden Case
Specification	Dimension: 2800 x 1200; T
Trademark	BEIENE
Origin	Qingdao, China
Production Capacity	200 Sets Per Month

Product Description

Main Technical Parameter

Description		Unit	Parameter
Cut Unit	Sawing RPM	RPM/Min	2800
	Motor Power	kw	2.2
Clamp Position Unit	X-axis Stroke	mm	2000
	Servo Power	kw	1.5
	Max Positioning Speed	mm/min	48
Feeding Unit	Y-axis Stroke	mm	300
	Servo Power	kw	1.5
	Max Positioning Speed	mm/min	16
Saw Blade Diameter		mm	405
Min Allowable Sheet Length		mm	40
Max Cut Size(W x H)		mm	200 x 20
Min Allowable Sheet Dimension(W x H )		mm	30 x 3
Air Pressure		Mpa	0.5-0.9
Total Power		kw	5.2
Main Machine Dimension (L× W)		mm	2800 x 1200
Total Weight		kg	1500

Advantages:
CNC Saw Machine is a self-developed equipment for quickly cutting busbar.1. This machine with high degree of vertical shearing ends, no collapse edge, reducing waste etc.2. This machine is equipped with automatic positioning device, stroke 2000 mm.3. This machine has high speed disk type alloy saw blades.4. This positioning system adopts high accurate ball screw transmission and straight guide to guarantee high precision and fast efficiency. Package and Shipment
