Automatic Busbar Machine Cutting Punching Processing for Busbar Joint Pack Monobloc
Automatic Busbar Processing Machine Cutting Punching for Busbar Joint MonoblocThe automatic joint connection bar process
Send your inquiryDESCRIPTION
Basic Info.
Model NO. | KDEQ-23-002 |
Origin | China |
Production Capacity | 10 Sets Per Months |
Product Description
Automatic Busbar Processing Machine Cutting Punching for Busbar Joint MonoblocThe automatic joint connection bar processing center is a machine with unmanned operation. Operator only needs to set the related data on the touch screen such as current ratings, quantity, hole distance, raw material length and etc. and strip conductors will be processed automatically. This will save labor cost and win stable and good quality. As connection bar type is different in the joint, machine can be customized according to the requirement to proceed hole punching, counter bore, cutting and etc..Technical Parameters of busbar joint processing machine with cutting punching functions:
No. | Parameters | ||
Model | KD-LJP-3 | ||
Force (KN) | Punch | 300 | |
Stretch | 300 | ||
Shear | 300 | ||
Stroke of X Axis | 1200mm | ||
Max. Speed of X Axis | 500mm/s | ||
Punching Stroke | 50mm | ||
Distance Accuracy of Two Holes | ±0.1mm | ||
Conductor(Aluminum, Copper) | Length | 6000mm | |
Width | 100mm~140mm | ||
Thickness | 2mm~4.5mm | ||
Max. Hydraulic Force | 31.5MPa | ||
Power | 380~415VAC 50~60Hz 10kW |
Introduction of our company's features:
We are the company specialized in busbar machine.Busbar machine means busbar production machine or busbar processing machine including mylar sleeve forming machine, busbar assembly machine, busbar riveting machine, busbar testing & inspection machine, busbar packing machine and busbar conveying machine. If you want to know how we use the machine to assemble the busbar, please kindly get the referenced pictures as below.
Step 1 Prepare all busbar finished components
Step 2 Use related busbar machines to process the busbar
Busbar machine copper processing
Need Kiande's busbar gas-hydraulic copper bar punching machine(This is one-time punching forming. In the market, some busbar manufacturer buys three-in-one busbar machine to bend and punch copper or aluminum bar. As the bar experiences many procedures, the accuracy is not good which will cause the phase distance too small to cause the short circuit.)
Busbar machine mylar sleeve processing machine polyester film forming machine
Need Kiande's mylar/polyester film forming machine. In the market, some busbar manufacturer requests workers to wrap the bar manually. Different workers have different workmanship. If employer meets the inexperienced workers, the wrapping part will have some gaps which will cause the short circuit.
Busbar machine busbar accessory 3M insulation film Conductor(Copper bar/Aluminum bar) end wrapping
Busbar machine busbar accessory Aluminum profile capped casting capped end / Busbar support
Busbar machine Busbar riveting machine
Busbar machine busbar inspection machine busbar testing machine
Busbar machine busbar packing machine busbar packaging machine
Busbar machine busbar accessory rivet the rivet is to connect the profiles instead of bolts more stable and strengthen
Busbar machine busbar accessory joint isolator Busbar joint pack
Plug-in contacts clips Busbar accessory Plug-in earth contact clip
