Auto CNC Busbar Processing Machinery Shearing and Flaring Machine

Overview Our Advantages 1. Japan YASKAWA Servo Control and Driver 2. Friendly HMI 3. Automatic Calculate Length and Posi

Send your inquiry

DESCRIPTION

Overview

Basic Info.

Model NO.	CNC-BD
Normal Force Flaring	300kn
Chief Clamp Stroke	1500 mm
Flaring Stroke	30 mm
Servo Control and Driver	Japan Yaskawa
Outside Dimension	7000X2200
Transport Package	Export Standard Free-Fumigation Wooden Case
Specification	Total Weight: 2700kgs
Trademark	BEIENE
Origin	Shandong, China
HS Code	8462
Production Capacity	200 Sets Per Month

Product Description

Auto CNC Busbar Processing Machinery Shearing and Flaring Machine

Our Advantages

1. Japan YASKAWA Servo Control and Driver

2. Friendly HMI
3. Automatic Calculate Length and Position4. Flaring with Flexible Angle .
5. Less Labor but High Efficiency and High Accuracy6. One Time Completed Length cutting and Flaring
Specification

Descriptions		Unit	Data
Nominal Force	Cutting		By Sawing 305mm
Nominal Force	Flaring	kN	300
X Axis Speed		m/min	48
Chief Clamp Stroke X1-Way		mm	1500
Aided Clamp Stroke X2-Way		mm	2000
Y Axis Stroke		mm	250
Flaring Stroke		mm	30
Station	Sawing	Set	1
Station	Flaring	Set	1
Tolerance		mm/m	±0.2
Air Source		MPA	0.6-0.8
Max Sheet Size(L×W×T)		mm	6000×120×7mm
Min Sheet Size(L×W×T)		mm	500×50×5mm
Total Power		kW	12KW
Machine Size:L×W		mm	15000*3000mm

Configuration

Control Unit
No.	Descriptions	Brand
1	PLC	OMRON
2	Sensor	Telemacanique fm Schneider
3	Control Button	OMRON
4	Touch Screen	OMRON
6	AC Contactor	ABB
7	MCCB	ABB
8	Switch	OMRON
9	Hydraulic Motor	WN
10	Servo Motor	YASKAWA
11	Servo Driver	YASKAWA

Transmission Unit:
Serial number	Name	Brand
1	Precise Guide Rail	Taiwan HIWIN
2	Precision ball screw	Taiwan HIWIN
3	Bearing	Japan NSK
Hydraulic Unit:
Serial number	Name	Brand
1	Solenoid Valve	ATOS
2	High-pressure Pipe	Riva flex
3	High pressure oil pump	SG Piston of Rexroth
